Wenzel LH87 -
gantry three-axis measuring machine (CMM)
range 800 x 1,500 x 700
maximum load 800 kg
measurement of metals and plastics
2D and 3D measurement
measurements with and without CAD data
suitable for both piece and series production
Part sizes from 10 mm
Scanning of almost any surface
2D and 3D evaluation
Data export for further processing (reverse engineering, CAD data creation, drawing)
Suitable for both piece and series production
Parts require special treatment before measuring - spraying with a mixture of alcohol and titanium oxide + sticking of reference points
Only 2D measurement
Advantage of zoom option - screen details
Roughness meter - DIAVITE DH-8
high-precision surface roughness meter for general use in the inspection room.
memory for 50 measurements
5 measuring lengths, selectable between 0.5 and 15.0 mm
selectable measuring speed
8 measurement programs
Spectrophotometer – Konica Minolta - type : CM – 25cG
is a portable colour and gloss meter with 45° geometry and a high performance 60° gloss sensor.
used in a number of industries, including automotive interiors.
the perfect 45° circular optical system achieves high accuracy and repeatability of measurements.
Coating thickness measurement
PosiTector200 coating thickness gauge - De Felsko
The PosiTector 200 is a handheld thickness gauge that uses the non-destructive ultrasonic principle to measure coating thickness on a wide range of substrates.
Climatic chamber - Votsch VC3 4060
used for alternating climate tests
temperature range from -40 ºC to +180 ºC
temperature and relative humidity control
relative humidity control from 10% to 98% RH
chamber working volume up to 600 litres
test space dimensions: 950 x 800 x 800 mm
capacity up to 160 kg
Tensile testing machine – Zwick/Roell Z050
used to determine tensile, compressive and bending properties
test load 50 kN
test height 1892 mm
test width 630 mm
Melt flow index test Zwick / Roell
– type : Mflow BMF
measurement of melt flow index of thermoplastic polymers.
MFR measurement (weight)
MVR measurement (volume)
according to ISO 1133
